9 Series Hotel Electronic Door Locks K1S Motise Mifare 1K S50 Card Required

I'm Online Chat Now

9 Series Hotel Electronic Door Locks K1S Motise Mifare 1K S50 Card Required

China 9  Series Hotel Electronic Door Locks K1S Motise Mifare 1K S50 Card Required supplier
9  Series Hotel Electronic Door Locks K1S Motise Mifare 1K S50 Card Required supplier 9  Series Hotel Electronic Door Locks K1S Motise Mifare 1K S50 Card Required supplier

Large Image :  9 Series Hotel Electronic Door Locks K1S Motise Mifare 1K S50 Card Required

Product Details:

Place of Origin: CHINA
Brand Name: Xeeder
Certification: CE
Model Number: L9208-M1

Payment & Shipping Terms:

Minimum Order Quantity: 100
Price: USD290/PCS
Packaging Details: 10pcs/Carton at 74.0X42.0X32.0CM
Delivery Time: 5 work days
Supply Ability: 1000PCS/Month
Contact Now
Detailed Product Description
Material: Brass Color: Silver
Motise: K1S RFID Card: Mifare 1K,4K
Hotel Lock Software: V5.857 , V7 Emergency Key: Mechanical



L9208 Series Hotel Lock is grace style model in xeeder hotel lock product line.

L9208-M1 Series hotel lock is Classic model of 9 Series.



BENEFITS


Stainless steel panel
RFID MIFARE® technology,100,000 times write life for keycard, contactless reading keycard
ANSI mortise
Free-engage while locking
Powered by AA battery,easy replace new
Openings 20,000 times for one new battery pack
Mifare 1K S50 card required
Audit trail records the latest 800 lock transactions.
Low Battery Voltage warning(beep and red light)
Passage mode activate by passage card for meeting case
Do not disturb(DND)function for hotels:While thumb turn is on from inside,the lock will refuse the keycard outside by show red light
Panic release function: the deadbolt and latch are automatically retracted by inside handle shaking to easy egress when emergency happens
Xeeder Hotel Lock System™ required
40mm-50mm thickness door
Each Xeeder hotel lock equipped double clock, control the guests check-in and departure time accurately, Make your management of rooms easily.


SPECIFICATIONS



Model L9208-M1
Low power alarm voltage 4.8V
RFID Working Frequence 13.56M Hz (ISO14443)
RFID Standard Mifare Classic 1K,4K
Working Distance 45mm Max
Working temperature 0-60℃
Working Humidity 15~85%RH
Static current < 30uA
Working current < 150mA
Open Door Event Memory 800 Transactions include Time/Date/Card ID/Card type/Room ID
Software Xeeder Hotel Lock System V5.857 , V7
Gross Weight 3.1KG
Package 10pcs/Carton at 74.0X42.0X32.0CM
Content Items Front/Back panel,mortise,cylinder,keyx2,battery-pack,manual/Strike


Model: L9208-M1
Power: LR6 (AA)battery x 4pcs
Low power alarm voltage:4.8V
Communication: 13.56MHz RFID(with keycard)/infrared (with LMA or WDR)
Card support: MIFARE® S50 plus S70
Working Distance: 45mm Max
Working Temperature: 0-60℃
Working Humidity: 15~85%RH
Static current: < 30uA
Working current: < 150mA
Memory: 800 Transactions include Time/Date/Card ID/Card type/Room ID
Software: XEEDER Hotel lock system™
Gross Weight: 3.1KG
Package: 10pcs/Carton at 74.0X42.0X32.0CM
Content: Front/Back panel,mortise,cylinder,keyx2,battery-pack,manual/Strike
(no battery included, no card)


USEAGE


Guest card: Reception complete program Guest card by give a begin and expiry date for a room(rooms). Guest access room by read this card on lock
Master card:Hold by housekeeping to access to all rooms of hotels
Floor card: Hold by clean staff to enter the rooms in one floor.
Building card: Hold by manager to enter the rooms in one building
Passage card: Once this card been read on one door, this door could be acceess by without reading keycard
Emergency card: Enter the all rooms
